-Imaging Device 3-chips 1/2.8 type “Exmor” CMOS Sensor
-Microphone Omni-directional stereo electret condenser microphone.
-Built-in Optical Filters OFF: Clear, 1: 1/4ND, 2: 1/16ND, 3: 1/64ND
-Effective Picture Elements Approx. 2.07M
-Gain Selection -6, -3, 0, 3, 6, 9, 12, 15, 18, 21, 24, 27, 30 dB, AGC
-Minimum Illumination 50i : 1.0lux(1/25 Shutter Speed, iris/gain Auto) or 60i : 1.2lux(1/30 Shutter Speed, iris/gain Auto)
-Shutter Speed (Time) 1/3 -1/10,000
-Slow & Quick Motion Function 1080p: Frame rate selectable 1.2.3.6.12.25,50 fps
-Operating Temperature 32°F to 104°F
-Power Consumption Approx. 7.5 W (while recording with viewfinder and AVCHD 1080/50i or 60i FX)
-Approx. 7.8 W (while recording with LCD and AVCHD 1080/50i or 60i FX)
-Power Requirements DC In: 8.4V
-Battery: 7.2 V
-Filter Diameter M72 mm
-Focal Length f=4.1 – 82.0mm
-equivalent to f=28.8 – 576mm on 35 mm lens(16:9)
-equivalent to f=35.2 – 705mm on 35 mm lens(4:3)
-Focus AF/MF selectable, 10 mm to ∞ (Wide), 800 mm to ∞ (Tele)
-Image Stabilizer ON/OFF selectable, shift lens
-Iris F1.6 – F11 auto/manual selectable
-Zoom Ratio Selectable 20x (optical), servo/manual
-Audio In XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable-
-Audio Out Stereo mini jack (x1)
-Composite Video Out BNC (×1), Composite 1.0Vp-p, 75 Ω
-DC In DC jack
-Digital Audio/Video Output(s) HDMI connector – Type A (1)
-Earphone Stereo mini jack (x1)
-Remote Stereo mini mini jack (x1)
-SDI Out BNC type (x1), SD/HD/3G(Level-B) selectable SMTPE 259M/292M/424M/425M standards
-USB Multi/Micro USB jack (x1)
