-Built-in Optical Filters 1: Clear, 2: 1/4ND, 3: 1/16ND, 4: 1/64ND
-Effective Picture Elements 1920 (H) x 1080 (V)
-Gain -3, 0, 3, 6, 9, 12, 18, 24 dB
-Horizontal Resolution 1,000 TV lines or more (1920 x 1080i mode)
-Imaging Device 3-chip 1/2-type “Exmor” Full HD CMOS
-Minimum Illumination 0.04 lx (typical) (1920 x 1080/59.94i mode, F1.6, +42 dB gain, with 64-frame accumulation)
-Optical System F1.6 prism system
-S/N Ratio 60 dB (Y) (typical)
-Sensitivity (2000 lx, 89.9% reflectance) F11 (typical) (1920 x 1080/59.94i mode) F12 (typical) (1920 x 1080/50i mode)
-Shutter Speed (Time) 1/60 sec to 1/2,000 sec + ECS (Extended Clear Scan)
-Slow & Quick Motion Function 720p: Frame rate selectable from 1 fps to 60 fps 1080p: Frame rate selectable from 1 fps to 30 fps
-Slow Shutter 2, 3, 4, 5, 6, 7, 8, 16, 32, 64-frame accumulation
-White Balance Preset (3200K), Memory A, Memory B/ATW
-Operating Temperature 32° F to 104° F
-Power Consumption Approx. 25W (with viewfinder, lens and microphone while recording)
-Power Requirements DC 12 V
-Audio Input XLR-type 3-pin (female) (x2), Line/Mic/Mic +48 V selectable
-Audio Output XLR-type 5-pin
-DC Input XLR-type 4-pin
-DC Output 4-pin
-Genlock Input BNC (x1)
-HDMI Output A type (x1)
-MIC XLR-type 5-pin
-Remote 8-pin
-SDI Output BNC (x2), HD-SDI/SD-SDI selectable
-Speaker Output Monaural
-Timecode Output BNC (x1)
-USB USB device B Type (x1), host A Type (x1)
-Video Output BNC (x1) HD-Y or Analog composite
-i.LINK IEEE 1394, 6-pin (x1), HDV (HDV 1080i )/DVCAM stream input/output *3 , S400
-Filter Diameter M82 mm, pitch 0.75 mm (on lens)
-Focal Length f = 5.8 mm to 93 mm (equivalent to 31.4 mm to 503 mm on 35 mm lens)
-Focus AF/MF/Full MF selectable 800 mm to ∞ (MACRO OFF) 50 mm to ∞ (MACRO ON, Wide) 782 mm to ∞ (MACRO ON, Tele)
-Iris F1.9 to F16 and Close, Auto/Manual selectable
-Lens Mount Sony 1/2-inch type bayonet mount
-Zoom System 16x (optical), servo/manual (AF lens for PXW-X320)
