General:
-Rated Power Output 10 Watts (+40 dBm)
-Power Input 1 Watt (+30 dBm)
-Gain 10 dB
-Operating Bandwidth 50 MHz
-Input/Output Impedance 50 Ohms (Nominal)
-RF Connectors N-Type
-Remote Connector D9-F
-Cooling Dual Fan Forced Air Over Heat Sinks
Management:
-Front Panel Indicators Power On, Output Power Level
-Remote On/Mute, Status, Output Power Level
Physical:
-Power Requirements Universal AC 90-260 V, 47-63 Hz,
-80 Watts (Consult Factory for DC)
-Mount 19” Rack Mount – 2 Rack-units
-Operating Temp. Range -20ºC to +60ºC Ambient
-Operating Humidity 90% (Non-condensing)
