-Correction Resolution:Corrects to ±1 sample (±23 μs) -Maximum Delay Error Correction:16 seconds -Time Required to Correlate Delay Errors::Small delay errors (up to 0.4 seconds) require up to 30 seconds to correlate; delay errors of 10 seconds could require as much as 3.5 minutes. -Time Required to Correct Delay Errors:Correction rate is user-programmable between 1 and 1000 samples per second (23μs/sec to 23ms/sec). -“Catch-Up” Button . . .

Read More

-Correction Resolution:Corrects to ±1 sample (±23 μs)
-Maximum Delay Error Correction:16 seconds
-Time Required to Correlate Delay Errors::Small delay errors (up to 0.4 seconds) require up to 30 seconds to correlate; delay errors of 10 seconds could require as much as 3.5 minutes.
-Time Required to Correct Delay Errors:Correction rate is user-programmable between 1 and 1000 samples per second (23μs/sec to 23ms/sec).
-“Catch-Up” Button Feature:A front-panel menu item, also accessible via the Web Interface, permits a manual time alignment quick reset to a previous long-term mean value. This obviates correlation acquisition and brings time alignment close to the required figure.

Read Less
