-Analog Modulation Capability 150% at positive peak at rated power
-Frequency Stability +/- 5 Hz between 0 and 45 ° C. In digital or hybrid mode the stability depends on the driver
-Response of Audio +/- 0.5 db between 20 and 15,000 Hz, referred to 1,000Hz and 95% modulation
-Total harmonic distortion Less than 1% between 20 and 15,000 Hz, at 95% modulation and nominal power
-Distorsion by Intermodulation Less than 2% at rated power and 85% modulation, with 1,000 and 400 Hz signals in the 1: 1 ratio
-Emission of Non-Essential Harmonics and Radiation Complies with FCC
-Electric Power Consumption 37,500 VA or less, with 0% modulation
-Impedance Input (Audio) 600 Ohms balanced
-Audio Input Level +10 dBm for 100% modulation.
-Adjustable between 0 and +12 dbm
-RF Impedance Impedance 50 Ohms Unbalanced
-Modulation Capacity
-120% positive peak modulation: 39 KW
-130% positive peak modulation: 36 KW
-150% positive peak modulation: 30 KW
-Efficiency Up to 93% (*)
-Environment Power Supply Three-phase supply 220/380 VAC, 50/60 Hz
