-Measurement Conditions Measured balanced XLR in to XLR out, 20 Hz – 20 kHz, minimum gain, pad out
-Dynamic Range 112 dB
-Signal to Noise Ratio ‐90 dB
-Frequency Response 0 / ‐0.25 dB @ 20 Hz, 0/‐0.5 dB @ 20 kHz
-THD+N System Peak Level THD+N: 0.0055% ‐68 dBu @ +17 dBu output, 1 kHz
-System Line level THD+ N: 0.0022%, ‐84 dBu @ +9 dBu output, 1 kHz
-Headroom +18 dB
-Operating Level 0 dBu, internal
-dBFS Alignment +18 dBu = 0 dBFS (+22 dBu at XLR output)
-Metering Meter Calibration: 0 dB meter = ‐18 dBFS (+4 dBu at XLR out)
-Meter Peak indication: ‐3 dBFS (+19 dBu at XLR out)
-Meter Type: Fast (peak) response
-Sampling Rate 48 kHz +/‐100 PPM
-ADC 24-bit Delta-Sigma
-DAC 24-bit Delta-Sigma
-Latency 1.49 ms (local XLR in to XLR out)
-0.68 ms (local XLR in to digital out)
-USB USB Playback: 2 channel, WAV, FLAC 44.1 / 48 kHz
-USB Record: 2 channel, 48 kHz / 16-bit – WAV
-I/O Port 64 channel bi-directional
-I/O Card A&H ACE, MADI, Dante, ES, Waves, MMO (optional)
-Operating Temperature 32 to 95°F (0 to 35°C)
-Mains Power 100 ‐ 240 VAC, 50 / 60 Hz, 110 W max
